In 2016, MANFISA began producing drawn wire for welding purposes. Due to the specific characteristics of this product, both technical and in terms of complying with different specifications and implementing regulations, a new Division was created: MANFISA WELDING.

In MANFISA WELDING we produce weld metal exclusively made from aluminium. In order to ensure maximum quality and to attend the specific needs of the welding market, a new production plant has been launched in 2019 with the sole purpose of producing aluminium weld metal.

We have new facilities and modern production equipment, as well as a new laboratory where we can monitor production and develop new I+D projects.

Alloys

Chemical composition of aluminium/aluminium alloys for welding as per en ISO 18273.

Alloy designations Chemical composition % Other elements Al
Numerical Chemical Si Fe Cu Mn Mg Cr Zn Ga V Ti Zr Be each total minim.
Al 1070 Al 99,7 0,20 0,25 0,04 0,03 0,03 - 0,04 0,05 0,05 0,03 - 0,0003 0,03 - 99,70
Al 4043 A Al Si 5(A) 4,5-6,0 0,6 0,30 0,15 0,20 - 0,10 - - 0,15 - 0,0003 0,05 0,15 Rest
Al 5183 Al Mg 4,5 Mn 0,7 0,40 0,40 0,10 0,50-1,0 4,3-5,2 0,05-0,25 0,25 - - 0,15 - 0,0003 0,05 0,15 Rest
Al 5356 Al Mg5Cr(A) 0,25 0,40 0,10 0,05-0,20 4,5-5,5 0,05-0,20 0,10 - - 0,06-0,20 - 0,0003 0,05 0,15 Rest
Al 5554 Al Mg2,7Mn 0,25 0,40 0,10 0,50-1,0 2,4-3,0 0,05-0,20 0,25 - - 0,05-0,20 - 0,0003 0,05 0,15 Rest
Al5754 Al Mg3 0,40 0,40 0,10 0,50 2,6-3,6 0,30 0,20 - - 0,15 - 0,0003 0,05 0,15 Rest

Applications

Marine Industry

view

Boiler and Pressure Vessel industry

view

Metal carpentry, water driving, electrical elements

view

Automotion

Lorem ipsum

view

Railway, naval, offshore, criogenic tanks industry

Lorem ipsum dolor sit amet, consectetuer adipiscing elit, nonummy nibh euismod tincidunt.

view
